Function:
1. operating mode, you can choose to balance and identify patterns
2. parameter setting, divided into stable, standard, high sensitivity, user-defined mode, if the user does not use, so long as elections to the first three modes, the system will have some good arguments default
3. the search methods: depth and the general search
4. the critical point: the same machine as before, but if the two parameters is set when the first three modes can not be stressed, System Preferences Well, when you can only customize the settings, the sensitivity of the back is the same
5. the volume can be set from 0-100
6. the sound frequency is the same
7. metallic sound point: non-ferrous metals, gold and silver three, and only when
adjusted in the identification mode, to balance this menu is not adjustable, three horizontal lines show
8. Alarm, there are two kinds of continuous and mutant
9. in the mutant mode, the alarm can be adjusted
10. alarm equipment, you can choose headphones wireless headphones and the general alarm, select the headset, you can adjust the transmission frequency to avoid interference with radio equipment in and around
11. the backlight time can be set to save power
12. language, English operation
13. the remaining power, you can display 0-100%, in the standby interface is
divided into four cells of the battery power display
14. have set the right button to press after the return to standby mode
Parameters:
Rod length 1.3 m,
Weight: 9.5KG
Signal frequency, 9.6KHZ Sound frequency, can be adjusted
Power Supply: DC12V power supply box, charge can be directly connected to 12V power supply, do not use the battery charger, car charger can also be used
Packing List:
1.Detector Host
2.Host backpack
3.Power box
4.Coil
5. A Set of Detecting connection rod(2 pieces as a set)
6. Arm cup
7. Hand supports
8. Recharge
9. Signal wire
10.User manual
Specification:
1.Detecting Depth: 2.5-5m
2.Signal Frequency: 9.6KHz Audio Frequency:400Hz
3.Power Supply:DC12V(Built-in rechargeable battery)
4.Power Consumption:0.8W Connecting Rod Length: 1.3m
5.Net Weight: 4.2KG Gross Weight:5.1KG
6.Package Size: 31*14*85.5 cm
