. Modular electromagnetic force sensor
. Weighing range indicat, white light LCD display
. High sensitivity light touch buttons
. Under hook recessed
. The glass door lock to protecting transportation
. RS232 interface module, USB interface module, built-in clock
. Independent “Tare”and “zero” buttom, two-way communication
. Four level shockproof
. Dynamic temperature compensation
. Weighing speed adjustable, showing way adjustable
|
|
JA1003
|
JA1203
|
JA2003
|
JA3003
|
JA4103
|
JA5003
|
|
Weighing Capacity（g）
|
100
|
120
|
200
|
300
|
410
|
500
|
|
Readability(g)
|
0.001
|
0.001
|
0.001
|
0.001
|
0.001
|
0.001
|
|
Repeatability(≤g)
|
±0.001
|
±0.001
|
±0.001
|
±0.001
|
±0.001
|
±0.001
|
|
Linearity(≤g)
|
±0.002
|
±0.002
|
±0.002
|
±0.002
|
±0.002
|
±0.002
|
|
Pan Size（mm）
|
Ф90
|
Ф90
|
Ф90
|
Ф90
|
Ф90
|
Ф90
|
|
Gross Weight( kg)
|
7.5
|
|
Net Weight (kg)
|
5.5
|
|
Dimension（mm）
|
365×223×338
|
|
Packing Measurement (mm)
|
500×310×450
|
|
|
