Conductivity Meter DDS-11A
Product Description
MODEL:DDS-11A Conductivity 1.With 3 1/2 LED,display is clear and precision is high. 2.Electrode constant compensation. 3.Manual temperature compensation. 4.Output signal (0-10)mV.
Technical Parameters:
1. Measuring range:
The measuring range is (0~2*10^5) uS/cm, the instrument has five ranges and can be changed through band switch by manual (by electrode with constant).
|
Range Types |
Measurement Range |
Resolution |
|
2μS/cm |
（0.001~2）μS/cm |
0.001μS/cm |
|
20μS/cm |
（0.01~20）μS/cm |
0.01μS/cm |
|
200μS/cm |
（0.1~200）μS/cm |
0.1μS/cm |
|
2mS/cm |
（0.001~2）μS/cm |
0.001mS/cm |
|
20mS/cm |
（0.01~20）μS/cm |
0.01mS/cm |
NOTE:To measure high conductivity ,a larger constant electrode is commonly used. If the conductivity is over 10000 uS/cm,the electrode with constant of 10cm-1 is used and the measuring range is extended to 2*105 uS/cm.
Packing List
|
No. |
Descriptions & Specifications |
Quantity |
|
1 |
DDS-11A |
1 |
|
2 |
DJS-1C |
1 |
|
4 |
Electrode holder |
1 |
|
5 |
Power supply |
1 |
|
6 |
Operating Manual |
1 |
|
7 |
BGXP200mA*20 |
2 |
|
8 |
Warranty Card |
1 |
|
9 |
Certification |
1 |
